MAXON – 8111 – SAFETY VALVE

‹Return to Previous Page
Bug Fix

Product Information

Categories: ,

MAXON Series 8000 Valves are pneumatically actuated valves with a powerful closing spring and a large, top-mounted 360-degree open-shut visual position indicator. The Series 8000 can be ordered with a wide range of internal trim options to handle general purpose or corrosive gases and comes in a compact, space-saving design. The Series 8000 provides simple installation and low maintenance for trouble-free, long-term uninterruped operation.

REQUEST A QUOTE

MAXON – 8700 - PARTS

SWITCH
MAXON - SAFETY VALVE - 8111 - limit switch

SWITCH KIT MODELS AVAILABLE:

  • VOS1 / VCS1 SWITCH KIT
  • VOS2 / VCS2 SWITCH KIT
SOLENOID
MAXON - SAFETY VALVE - 8111 - Solenoid 2

SOLENOID MODELS AVAILABLE:

  • SOLENOID 24 VDC
  • SOLENOID 120 VAC / 50 HZ
  • SOLENOID 120 VAC / 60 HZ
  • SOLENOID 230 VAC / 50 HZ
  • SOLENOID 230 VAC / 60 HZ
INDICATOR

VISUAL INDICATOR MODELS AVAILABLE:

  • VISUAL INDICATOR – RED CLOSED
  • VISUAL INDICATOR – RED OPEN
  • VISUAL INDICATOR – YELLOW OPEN

Tags: , ,
Description

Description

  • Electrically actuated valves shut off oil lines reliably.
  • Application flexibility provided with 3/8″ through 2”” diameter line sizes, Cv flow factors up to 218, and line pressures up to 550 PSIG.
  • Handles flowing fluid temperatures:
    • Swinging gate bodies from -20°F (-28°C) to +550°F (+288°C)
    • Any ambient temperature from -20°F (-28°C) to +140°F (+60°C)
  • Various application requirements met with manual reset or automatic reset motorized operators.
  • Minimize line pressure drops with straight-through flow swinging gate valve bodies
  • Positive visual indication of valve body position is provided by large two-color open-shut indicator.
  • Installation piping convenience obtained from field rotatable top assemblies.
  • Special operating features available in Special Service Packaged versions.
  • Micro-lapped seating wears in, not out.
DOWNLOADS

PRODUCT OVERVIEW BULLETIN

SPECIFICATION BULLETIN

VALVE MAINTENANCE BULLETIN

LEAK TESTING

VALVE SIZING CHARTS

Product brand

MAXON

Related Products

Quick View

MAXON BLOWER GASKET – OVENPAK 1

,
MAXON blower gasket for the ovenpak 1 is to be installed on the discharge flange of the integral combustion air blower. Designed to provide an airtight seal around the outlet of the blower flange, this gasket should provide a worry free seal under a variety of environmental conditions. The gasket is considered a consumable item and should be replaced during regularly scheduled burner maintenance.
QUOTE REQUEST
Maxon Safety Valve MM11 - 300CMM11 Quick View

MAXON – MM11 – SAFETY VALVE

,

MAXON's Electro-Pneumatic Shut-Off Valves are ideally suited for reliable shut off of various fuel gases and liquids. MAXON gas valves require only a power source from your burner management system or DCS and an instrument air feed. MAXON shut off valve operating pressures and valve Cv's are among the highest available in the industry meaning you can move more fuel in smaller size valves than competitive products.

REQUEST A QUOTE

MAXON – MM11 - PARTS

SOLENOID
MA11 - Part #1 Solenoid

SOLENOID MODELS AVAILABLE:

  • SOLENOID 24 VDC
  • SOLENOID 120 VDC
  • SOLENOID 120 VAC / 50 HZ
  • SOLENOID 120 VAC / 60 HZ
  • SOLENOID 208 VAC / 50 HZ
  • SOLENOID 230 VAC / 50 HZ
  • SOLENOID 230 VAC / 60 HZ
SWITCH KIT
MA11 - Part #3 Switch kit

SWITCH KIT MODELS AVAILABLE:

  • VOS1/NONE SWITCH KIT
  • VOS1/VCS1 SWITCH KIT
  • VCS2/VOS1 SWITCH KIT
  • VOS2/VCS2 SWITCH KIT
  • VOS1HC/VCS1HC SWITCH KIT

Quick View

GAS INLET GASKET – OVENPAK 2

,
MAXON gas inlet gasket is to be installed on the gas inlet flange of the burner casing. Designed to provide an gastight seal around the inlet flange of the burner casing, this gasket should provide a worry free seal under a variety of environmental conditions. The gasket is considered a consumable item and should be replaced during regularly scheduled burner maintenance.
QUOTE REQUEST
Quick View

MOTOR BRACKET – OVENPAK 2

,
MAXON Connecting brackets and linkage assemblies are available in 4 main versions:
  • Maxon SMARTLINK DS drive motors.
  • Honeywell MODUTROL drive motors.
  • Honeywell HERCULINE drive motors.
  • Barber-Colemand drive motors.
Special assemblies can also be engineering upon request.
QUOTE REQUEST
Quick View

GUIDE TUBE – OVENPAK 2

,
MAXON guide tubes allow for the simple installation of either UV flame detection cells of flame rods. Designed to penetrate through the entire burner to visualize the flame directly of the nozzle tip, the carbon steel guide tubes are available with either NPT or TEC end connections.
QUOTE REQUEST
Quick View

MAXON – 4700 SERIES – SAFETY VALVE

,

Maxon general purpose electrically actuated valves shut off oil lines in less than one second. A variety of body materials and body connections provide reliable operation even for highly corrosive fuels and for oxygen with Maxon's long-lasting metal-to-metal seating.

REQUEST A QUOTE

MAXON – 4700 - PARTS

SOLENOID
Maxon Safety Valve 4700 - PART1 - Solenoid

SOLENOID MODELS AVAILABLE:

  • 24 VDC SOLENOID
  • 24 VAC SOLENOID
  • 46 VAC SOLENOID
  • 100 VAC SOLENOID
  • 120 VAC SOLENOID
  • 208 VAC SOLENOID
  • 230 VAC SOLENOID
  • 345 VAC SOLENOID
  • 460 VAC SOLENOID
MOTOR
Maxon-SafetyValve-4700-PART2-Motor

MOTOR MODELS AVAILABLE:

  • 2,5 SEC, 120 VAC / 50 & 60 HZ MOTOR
  • 2,5 SEC, 230VAC / 50 & 60 HZ MOTOR
  • 6 SEC, 120 VAC / 50 & 60 HZ MOTOR
  • 6 SEC, 230 VAC / 50 & 60 HZ MOTOR
SWITCH KIT
Maxon-SafetyValve-4700-PART3-SwitchKit

SWITCH KIT MODELS AVAILABLE:

  • VOS 1 LIMIT SWITCH
  • VOS 2 LIMIT SWITCH
  • VCS1 LIMIT SWITCH
  • VCS2 LIMIT SWITCH

Quick View

MIXING CONE – OVENPAK 2

,
"MAXON mixing cones are availble in 3 versions:
  • Standard cast iron mixing cone, suitable for most process applications.
  • Excess air cast iron mixing cone, allowing +/-10% more air through the burner with the same overall pressure drop.
  • Stainless steel mixing cone, suitable for high temperature or highly corrosive applications.

QUOTE REQUEST
Quick View

LINKAGE KIT – OVENPAK 2

,
MAXON linkage kits allow for the direct coupling of the internal air/gas butterfly valves of the Ovenpak 2 burner series. The kit includes:
  • Butterfly dics
  • Linkage arms
  • Pins
  • Seals
  • And bushings to allow fo the complete replacement of the control internals.
QUOTE REQUEST
Quick View

MAXON – 8700 SERIES – SAFETY VALVE

,

Maxon general purpose electrically actuated valves shut off oil lines in less than one second. A variety of body materials and body connections provide reliable operation even for highly corrosive fuels and for oxygen with Maxon's long-lasting metal-to-metal seating.

REQUEST A QUOTE

MAXON – 8700 - PARTS

MOTOR
MAXON-SAFETY-VALVE-8700-Part3-Motor

MOTOR MODELS AVAILABLE:

  • 6 SEC, 120 VAC / 50 & 60 Hz MOTOR
  • 6 SEC, 230 VAC / 50 & 60 Hz MOTOR
SWITCH
MAXON-SAFETY-VALVE-8700-Switch Kit

SWITCH KIT MODELS AVAILABLE:

  • VOS 1 LIMIT SWITCH
  • VOS 2 LIMIT SWITCH
  • VCS1 LIMIT SWITCH
  • VCS2 LIMIT SWITCH
BOARD
MAXON-SAFETY-VALVE-8700-Part1-Circuit Board

CIRCUIT BOARD MODELS AVAILABLE:

  • 120 VAC CIRCUIT BOARD
  • 230 VAC CIRCUIT BOARD
CLUTCH
MAXON-SAFETY-VALVE-8700-Part2-Clutch Assembly

CLUTCH KIT MODELS AVAILABLE:

  • VOS 1 LIMIT SWITCH
  • VOS 2 LIMIT SWITCH
  • VCS1 LIMIT SWITCH
  • VCS2 LIMIT SWITCH

Quick View

FIRING SLEEVE – OVENPAK 2

,

MAXON firing sleeves are available in 5 versions:

  • Standard sleeve is 8″ long, made of #310 SS, and is suitable for downstream temperatures up to 1000°F (538°C).
  • For higher velocities, specify 12″ long sleeve made of #310 SS for downstream temperatures up to 1000°F (538°C).
  • For higher downstream temperatures between 1000°F (538°C) and 1500°F (816°C), specify 8″ long, #RA 330 SS sleeve.
  • For higher velocities and downstream temperatures between 1000°F (538°C) and 1500°F (816°C), specify 12″ long, #RA 330 SS sleeve.
  • For refractory lined furnaces, specify 8"" refractory lined sleeve. "

QUOTE REQUEST
